Speeder 100
Original price was: kr9.999,00.kr8.999,00Current price is: kr8.999,00.
The entry level into our SPEEDER range, but still featuring a lightweight aluminium frame, full carbon forks and quality Shimano components. A fun packed and efficient commuter and fitness mile muncher.
- Description
- Additional information
- Sizes
- Spare Parts
Description
Our entry model into our SPEEDER range, the SPEEDER 100 brings the same high-quality aluminium frame and full carbon fork to the table as its more high-end family members, but combines it with high-value components. Powerful disc brakes enable perfect speed control, while the broad gear range of the triple chain ring drivetrain makes climbing a breeze and keeps top speeds high. Multiple fixing points allow bottle cages, fenders, kickstand and a rear rack to be fitted.
Fast and lightweight, the SPEEDER shares its genes with our road bike range. The geometry offers an extended reach for added stability while providing a more upright and comfortable riding position. The sporty yet comfort inspired geometry paired with control enhancing flat handlebars and powerful disc brakes make the SPEEDER ideal for fast commuting or fitness rides. Wider tyres and more tyre clearance underline the comfort element even further and give the SPEEDER more grip when it counts. Road.cc call the 900 an ‘excellent fast flat-bar road bike with awesome performance’ and the 200 ‘an enjoyable flat-barred flyer for fitness, commuting and everyday riding’.
Additional information
| Weight | 11 kg |
|---|---|
| Frame | |
| Frame size | |
| Color | |
| Brake System | Shimano MT200 |
| Rotors | Shimano RT10 |
| Brake Levers | |
| Headset | MERIDA M2331 Neck |
| Handlebar | MERIDA COMP TK |
| Handlebar Stem | MERIDA COMP CC |
| Grips | MERIDA EXPERT EC |
| Front Derailleur | |
| Shifters | Shimano Altus |
| Seat Post | MERIDA COMP CC |
| Seatclamp | MERIDA EXPERT |
| Saddle | MERIDA COMP SL |
| Pedals | VP VPE-891 |
| Chain | Sunrace CN-M84 |
| Chainguard | attached |
| Crankset | Shimano TY301 |
| Freewheel | Sunrace CSM558 |
| Front Hub | Shimano HB-QC300 |
| Rear Hub | Shimano FH-QC300-HM |
| Rims | MERIDA COMP SL |
| Front Tyre | Maxxis Detonator |
| Rear Tyre | |
| Axles | QR |
| Spokes | Black stainless |
| Weight | 11 kg |
| Structural Weight |
| FRAME SIZE | XXS | XS | S | M | L | XL |
|---|---|---|---|---|---|---|
| TYRE SIZES | 28″ | 28″ | 28″ | 28″ | 28″ | 28″ |
| ST SEAT TUBE [MM] | 470 | 500 | 520 | 540 | 560 | 590 |
| TT TOP TUBE [MM] | 555 | 561 | 571 | 583 | 597 | 610 |
| CS CHAIN STAY LENGTH [MM] | 438 | 438 | 438 | 438 | 438 | 438 |
| HTA HEAD TUBE ANGLE [°] | 70 | 70.5 | 71 | 71.5 | 72 | 72 |
| STA SEAT TUBE ANGLE [°] | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| BD BOTTOM BRACKET DROP [MM] | 65 | 65 | 65 | 65 | 65 | 65 |
| HT HEAD TUBE [MM] | 150 | 160 | 170 | 190 | 215 | 240 |
| FL FORK LENGTH [MM] | 395 | 395 | 395 | 395 | 395 | 395 |
| R REACH [MM] | 389 | 392 | 398 | 404 | 410 | 416 |
| S STACK [MM] | 562 | 573 | 585 | 606 | 631 | 655 |
| WB WHEEL BASE [MM] | 1051 | 1053 | 1058 | 1066 | 1075 | 1088 |
| SH STAND OVER HEIGHT [MM] | 744 | 769 | 787 | 806 | 828 | 855 |
| No. | Item-No. | Name | Info | Pieces | Torque Nm |
|---|---|---|---|---|---|
| 1 | A2258000056 | CABLE PLUG | brake hose into down tube | 1 | |
| 2 | A2298000324 | SCREW | M5*P0.8 L10mm | 1 | 4-5 |
| 3 | A2240000010 | CABLE GUIDE | front derailleur cable below bottom bracket | 1 | |
| 4 | A2298000093 | SCREW | M4*P0.7 L6mm | 2 | 3-4 |
| 5 | A2298000068 | SCREW | M5*P0.8 L10mm | 2 | 4-5 |
| 6 | A2300000485 | SCREW | M4*P0.7 L6mm | 2 | 3-4 |
| 7 | A2311000119 | RD-HANGER | DH-072 for ROAD-RD | 1 | |
| 7 | A2311000120 | RD-HANGER | DH-074 for MTB-RD | 1 | |
| 8 | A2300000568 | SCREW | M3*P0.5 L6mm | 2 | 2-3 |
